Product Details:

1. Basic Parameters

Compressor TypeDC Dual Rotor Inverter Compressors
Rated VoltageDC 24V
Voltage range24V±10%
Rated Current12A
Maximum Current16A
Displacement2.8cm³/rev
Cylinder Number2
Motor Rotor Pole6
Maximum Compression Ratio6
Speed Range1800~4500rpm
Cooling Capacity(at 4500 rpm)465W(ASHRAE Conditions)
RefrigerantR134a
Max. Amount of Refrigerant110g
OilRL68H
Oil Charge50mL
Ambient Temperature-5~55℃
Evaporating Temperature-10~15℃
Condensing Temperature45~76℃
Weight1.3kg
Suction Tube(I.D)6.5mm
Discharge Tube(I.D)6.5mm

2. Cooling Capacity Curve

3. Compressor size

4. Drive board size
